Quantitative Filling Lighters’ Equipment. (MODEL NT-5XZ )

为适应打火机大量生产的需求，而自行开发设计的防爆型，全气动全自动化设备，本设备快速一次性完成对打火机底部的定量灌装充气，设备带有5个充气头，5个独立定量缸，一个操作两台，自动进出料。

To meet the large quantity demand of lighters’ production, we have development and design by our own this explosion proof,fully pneumatic,fully automatic equipment.Rapid and one-time achieve the quantitative filling for the bottom of lighers’, equipment with 5pcs filling heads, 5pcs independ quantitative cylinders, one person operate two equipment, inlet and outlet material automatically.

主要参数 Main Parameter

充气部位 Filling Position 底部Bottom

定量缸Quantitative Cylinders 5 PCS

充气头 Filling head 5 PCS

自动化程度 Automation Degree 全自动Fully Automation

产能 Production Capacity  6000-9000 pcs/hour

灌装量范围 Filling Quantity Scope 2-6 ml(special specifaction can be customized)

适用打火机尺寸Application for Lighter’s Size Within sizes of 12*30*90 mm

空气气源压力 Air Source Pressure 0.5-0.6 mpa

消耗气源Consumption Air Source  0.03 cbm/minute

设备外形尺寸Outline Dimensions 1500*1200*500 mm
